VoIPtalk is pleased to be the authorised UK distributor of Aastra IP telephones.

The Model 9133i is an advanced, fully featured multi-line IP Telephone that takes full advantage of VoIP technology by offering a flexible, interoperable solution at an affordable price.

The Aastra 9133i comes with a UK power supply. You can select a PoE converter from the options below if you wish to integrate your Aastra with a PoE network.

Need more information on the POE Converter?

• Enhanced Call Management — Large storage for personal directory, callers log, and redial list

• Tight Integration — Support for multiple IP telephony systems including BroadWorks®, Nortel, Sylantro, and Asterisk SIP

• Multiple Line/Call Appearance Lights — Support up to 10 simultaneous calls. Juggle multiple calls easily with a single press of a button

• Shared Call Appearances — Shared calls allow you to place a call on hold at one set and pick it up easily at another set

• Remarkable Audio — Quality speakerphone with excellent voice clarity and delivery

• Protect Your Investments — Firmware upgrades can be downloaded and installed in the field as standards develop and protocols evolve

• Less Wiring — Built in dual 10/100 switched Ethernet ports let you share a connection with your computer. Inline power upport eliminates the need for a power adapter

Product Specification

Physical
20.2 cm W x 19.5 cm D x 8.0 cm H (8.0”W x 7.7”D x 3.2”H)
842 g (29.7 oz)

Power
Compatible with IEEE 802.3af inline power device
Optional Power Over Ethernet (POE) injector available for networks that do not supply power

Handset / Headset
Modular RJ9 headset connector, compatible with amplified business headsets
Hearing aid compatible handset
Quality speakerphone

Display
3 line adjustable backlit display

Feature Keys
3 call appearance lines
4 navigational keys
7 programmable keys
10 predefined hard keys including Conference, Call Transfer, Redial, Options, Directory, Save, Delete, Speaker/Headset, Mute

Networking
Dual 10/100 Mbps switched Ethernet ports
Manual or Dynamic Host Configuration Protocol (DHCP) IP address setup
Time and date synchronization using SNTP
Built-in HTTP server for web administration and maintenance
Server provisioned user configuration files

Protocols / Codecs
IETF SIP (RFC3261)
G.711 µ-law / A-law
G.729

Feature Highlights*
Up to 10 call appearance lines
Personal directory
Call forward
Call transfer
Call waiting
Caller and calling line information
Callers log
Conference
Redial list
Live dial pad or pre-dial support
Broadsoft’s BroadWorks enhanced SIP – supports Intercom, Shared Call Appearances, CommPilot Call Manager
Nortel’s MCS SIP support – Conferencing, Voicemail, and NAT Traversal support

* Feature availability dependent on IP telephony system

Need more support? Click on the links below:

9133i Generic SIP User Guide (pdf)

9133i Data Sheet (pdf)

New Aastra Firmware now available.

Quick Setup Guide

Aastra 9133i configuration instructions
