The new GXP2010 Key System IP phone has a new sleek design and delivers excellent call quality and enterprise grade feature set that includes advanced XML capabilities, multi-party conferencing, multi-language support, presence and BLF (busy lamp field), security protection, automated provisioning, and broad compatibility with leading SIP platforms. The GXP2010 offers 4 lines, 18 programmable keys, 3 dynamic context-sensitive XML soft keys, dual switched 10M/100Mbps auto-sensing Ethernet ports with integrated PoE, and a large high-resolution backlit LCD display. As with all models in the GXP Series, this model supports comprehensive voice codecs and SRTP for privacy protection.

The GXP2010 was designed to be the cost-effective choice for the busy call center or small business that wants the feature functionality of a key-system. The 18 programmable speed-dial keys enable one-button access to office personnel and the 11 dedicated keys create one-button access to indispensable telephony features including hold, conference, mute, do-no-disturb, intercom, transfer, speaker and voicemail. This phone is ideal for enhancing office productivity and improving efficiency.

Product Features

Technical Features & Benefits

• Support SIP (RFC3261), TCP/IP/UDP, RTP/RTCP, HTTP, ARP, ICMP, DNS (A record and SRV), DHCP(both client and server), PPPoE, TFTP, NTP
• Dual switched 10/100Mbps Ethernet ports w/integrated Power-over-Ethernet (802.3af)
• Support NAT traversal (STUN, etc), server fail-over, SIP presence (SIMPLE), and more
• Backlit 240x120 high resolution graphic LCD with multi-level gray scales

Call Features & Benefits

• 4 lines indicators with individual SIP account profiles
• 18 programmable hard keys and 3 XML programmable context-sensitive soft keys
• Multi-line support of up to 22 call appearance lines with dual-color LED indicators
• Support Caller ID display or block, per call or permanent
• Call waiting, hold, mute, transfer (blind or attended), forward, and more
• Multi-party conferencing (up to 4-way) and shared line appearances
• Expandable through expansion key-modules (pending)
• And many more enterprise grade features

Handset Features & Benefits

• Full duplex speakerphone w/advanced audio echo cancellation
• Headset jack (2.5 mm and RJ11) for broad headset compatibility
• Secure and automated provisioning for mass deployment
• SRTP and TLS (pending) for privacy protection
• And many more enterprise grade features

Feature Specifications SIP Compliant and Protocols: SIP, TCP/IP/UDP, RTP/RTCP, HTTP, ARP, ICMP, DNS (A record and SRV), DHCP(both client and server), PPPoE, TFTP, NTP, etc.
Networking Interfaces: Dual 10/100mbps Ethernet ports (switched or routed).
Voice Codecs: G.711 (a/µ-law), G.723.1, G.729A/B, G.726, GSM, iLBC, and G.722 (wideband).
Superb Audio Quality: Advanced Digital Signal Processing (DSP), Silence suppression, VAD, CNG, AGC high fidelity wideband audio (G.722).
Custom Ringtone: Software Convert most music files to a Grandstream ringtone. Click here to download.
Advanced Functionality: Multi-line support, multi-party conferencing (4-way), multi-language support (MLS), headset enabled, expandable, intercom, AES encryption, etc.

Quick Setup Guide

Grandstream GXP-2010 configuration instructions
