Large display — Eight-line backlit screen
with six context sensitive softkeys provides more information and
flexibility in call handling
-
Enhanced Call Management — Large storage for
personal directory, callers log, and redial list
-
Tight Integration — Support for Sphericall
MGCP and multiple SIP IP telephony systems including BroadWorks®,
Nortel, Sylantro and Asterisk
-
Multiple Line/Call Appearance Lights — Support
up to 9 simultaneous calls. Juggle multiple calls easily with a single
press of a button
-
Shared Call Appearances — Shared calls allow
you to place a call on hold at one set and pick it up easily at another
set
-
Remarkable Audio — Quality speakerphone with
excellent voice clarity and delivery
-
Protect Your Investments — Firmware upgrades
can be downloaded and installed in the field as standards develop
and protocols evolve
-
Less Wiring — Built in dual 10/100 switched
Ethernet ports let you share a connection with your computer. Inline
power support eliminates power adapters
Physical
2 position desk stand
24.9 cm W x 14.7 cm D x 11.5cm D (9.8''W x 5.8''D x 4.5''H)
850 g (30.0 oz.)
Power
Compatible with IEEE 802.3af inline power device
Optional Power Over Ethernet (POE) injector available for networks that
do not supply power
Handset / Headset
Modular RJ9 headset connector, compatible with amplified business
headsets
Hearing aid compatible handset
Quality speakerphone
Display
3.5'' x 2.25'', 8 line, backlit display
Feature Keys
4 call appearance lines
4 navigational keys
6 customizable softkeys; programmable up to 18 functions.
8 predefined hard keys for most common call handling functions including
Call Transfer, Conference, Intercom, Hold, Redial, Mute
Networking
Dual 10/100 Mbps switched Ethernet ports
Manual or Dynamic Host Configuration Protocol (DHCP) IP address setup
Time and date synchronization using SNTP
Built-in HTTP server for web administration and maintenance
Server provisioned user configuration files
Protocols / Codecs
IETF SIP (RFC3261)
IETF MGCP (RFC3435)
G.711 µ-law / A-law
G.729
Feature Highlights*
Up to 9 call appearance lines
Personal directory
Call forward
Call transfer
Call waiting
Caller and calling line information
Callers log
Conference
Hold
Redial list
Live dial pad or pre-dial support
Broadsoft’s BroadWorks enhanced SIP – support for Intercom,
Shared Call Appearances, CommPilot Call Manager
Nortel’s MCS SIP support – Conferencing, Voicemail, and
NAT Traversal support
Sphere's Sphericall MGCP support - BLF, Intercom
* Feature availability dependent on IP telephony system
